TrackMaster™ Select Whipstock System

Applications

Three categories define the configuration options for the TrackMaster Select system:

TM Select Whipstock Mill v2 - Wellbore Integrity

Conventional Sidetracks

  • Single casing
  • Hard formation
  • Extended rathole
  • Elongated window

Advanced Sidetracks

  • Heavy wall, high strength casing
  • Corrosion-resistant alloy casing
  • Lowside exit
  • Dual and triple casing

Specialized Sidetracks

  • Custom multi-lateral junctions
  • Flow by access configurations

Operational Drivers

Planned

  • Multi-lateral
  • Production increase
  • Slot reuse
  • Cost reduction

Remedial

  • Obstruction
  • Collapsed casing
  • Directional issue

Benefits

  • Application-specific configuration options
  • One-trip solution  saves time and cost
  • Comprehensive planning process
  • Proprietary modeling software to predict window geometry and BHA pass-through
  • Increased durability and reliability
  • Improved milling efficiency in a broad range of casing and formations

Features

Mills

  • Bi-mill, tri-mill and quad-mill configurations
  • Customized cutting structures for all casing and formation types
  • Fabricated and integral mill designs

Whipstocks

  • Unique multi-ramp profile offers rapid cut out and extended full gauge window
  • Integral retrieval slot for whipstock recovery when required
  • Configurations options for multi-lateral and flow by applications

Anchors

  • Anti-rotation and high-axial-load slip design
  • Hydraulic and mechanical set actuation
  • High-pressure packer element option available
  • Large slip areas to reduce casing stress and provide more positive anchor set
